Resistor Calculator
Calculate resistor color codes, parallel/series resistance, and conductor resistance.
Resistor Color Code Calculator
Parallel Resistor Calculator
Provide all of the resistance values in parallel, separated by a comma ",", and click the "Calculate" button to determine total resistance.
Resistors in Series Calculator
Provide all of the resistance values in series separated by a comma ",", and click the "Calculate" button to determine total resistance.
Resistance of a Conductor
Use the following to calculate the resistance of a conductor. This calculator assumes the conductor is round.
Color Code Chart
| Color | Value | Multiplier | Tolerance | Temp Co. |
|---|---|---|---|---|
| black | 0 | 1 | N/A | 250ppm/K |
| brown | 1 | 10 | ±1% | 100ppm/K |
| red | 2 | 100 | ±2% | 50ppm/K |
| orange | 3 | 1000 | ±3% | 15ppm/K |
| yellow | 4 | 10000 | ±4% | 25ppm/K |
| green | 5 | 100000 | ±0.5% | 20ppm/K |
| blue | 6 | 1000000 | ±0.25% | 10ppm/K |
| violet | 7 | 10000000 | ±0.1% | 5ppm/K |
| grey | 8 | 100000000 | ±0.05% | 1ppm/K |
| white | 9 | 1000000000 | N/A | N/A |
| Gold | N/A | 0.1 | ±5% | N/A |
| Silver | N/A | 0.01 | ±10% | N/A |
Loading...
Decode and Calculate Resistor Values
Our Resistor Calculator helps you determine the resistance value from color codes and calculate the total resistance for series and parallel circuits.
What is a Resistor Calculator?
A Resistor Calculator is a multi-functional tool for electronics enthusiasts, engineers, and students. It primarily helps decode the color bands on a resistor to determine its resistance value in Ohms (Ω), tolerance, and sometimes its temperature coefficient. Additionally, it can calculate the total equivalent resistance for resistors connected in series or parallel, which is fundamental for circuit design and analysis.
How It Works: Color Codes & Formulas
The calculator employs different methods for each of its functions:
Color Code: Value = (Band1_Value × 10 + Band2_Value) × Multiplier
Series Resistance: R_total = R₁ + R₂ + ... + Rₙ
Parallel Resistance: 1/R_total = 1/R₁ + 1/R₂ + ... + 1/Rₙ
- For Color Codes: Select the number of bands (4, 5, or 6) and then choose the color for each band from the dropdowns. The calculator instantly displays the resulting resistance value, tolerance, and temperature coefficient (for 6-band).
- For Series/Parallel: Enter a comma-separated list of resistance values (in Ohms) into the appropriate text area and click calculate.
Interpreting the Results: Understanding the Values
For the color code calculator, the key result is the **resistance value in Ohms (Ω)**, often displayed in kΩ (kilo-ohms) or MΩ (mega-ohms) for larger values. The **Tolerance** (e.g., ±5%) tells you the acceptable range of the resistor's actual value. For series and parallel calculations, the **Total Resistance** is the equivalent resistance that the circuit presents, which is crucial for applying Ohm's Law.
Common Resistor Misconceptions
- Myth 1: You can read the bands in either direction. False. You must read the bands starting from the end that is closest to a lead. The tolerance band (usually gold or silver) is almost always the last band.
- Myth 2: A resistor's only job is to reduce current. While controlling current is a primary function, resistors are also used in voltage dividers, timing circuits, pull-up/pull-down networks, and for terminating signals.
- Myth 3: The physical size of a resistor doesn't matter. The physical size of a resistor indicates its power rating (in Watts). Using a resistor with too low a power rating will cause it to overheat and burn out, even if its resistance value is correct.
Frequently Asked Questions
How do you read resistor color codes?
To read resistor color codes, you identify the values of the first two (or three) bands, the multiplier of the next band, and the tolerance of the last band. For example, a 4-band resistor with Brown-Black-Red-Gold translates to 1 (Brown), 0 (Black), a multiplier of 100 (Red), and a tolerance of ±5% (Gold), resulting in a 1000 Ohm or 1kΩ resistor. Our calculator automates this process.
How do you calculate total resistance in series?
The total resistance of resistors in a series circuit is the sum of their individual resistances: R_total = R1 + R2 + R3 + ...
How do you calculate total resistance in parallel?
The total resistance of resistors in a parallel circuit is the reciprocal of the sum of the reciprocals of their individual resistances: 1/R_total = 1/R1 + 1/R2 + 1/R3 + ...
What do the bands on a resistor mean?
The bands on a resistor represent its electrical resistance value. For a 4-band resistor, the first two bands are significant digits, the third is a multiplier, and the fourth is the tolerance. 5- and 6-band resistors add an extra significant digit and sometimes a temperature coefficient band.
Practical Tips for Using Resistors
- Verify with a Multimeter: Always use a multimeter to confirm a resistor's value before placing it in a circuit, especially if the color bands are faded or hard to read.
- Consider Power Rating: Use Ohm's Law (P = I²R) to calculate the power that will be dissipated by the resistor and ensure it is below the component's wattage rating (e.g., 1/4W, 1/2W).
- Series vs. Parallel: Use resistors in series to achieve a higher total resistance. Use them in parallel to achieve a lower total resistance.
